9 KW Semi Automatic Gluer Machine Pitch For Offset Printed Carton

Product Details

Place of Origin: GUANGDONG, CHINA

Brand Name: WEPACK

Certification: CE,SGS

Model Number: XU-X2-1800

Payment & Shipping Terms

Minimum Order Quantity: 1 SET

Price: Negociated

Packaging Details: Wrapping film protective packaging in line with export cabinets

Delivery Time: 5-15 days

Payment Terms: L/C, T/T

Supply Ability: 30 sets per month

Get Best Price
Highlight:

Semi Automatic Gluer Machine

,

9 KW Semi Automatic Gluer Machine

Number Of Heads:
Two
Automation:
Semi-automatic
Stitching Speed:
500nails Per Minute
Type:
Stitcher
Dimensions:
4000mm X 3300mm
Suitable For:
Offset Printed Carton
Stitching Pitch:
30-120mm
Number Of Heads:
Two
Automation:
Semi-automatic
Stitching Speed:
500nails Per Minute
Type:
Stitcher
Dimensions:
4000mm X 3300mm
Suitable For:
Offset Printed Carton
Stitching Pitch:
30-120mm
9 KW Semi Automatic Gluer Machine Pitch For Offset Printed Carton
9 KW Semi Automatic Gluer Machine ,Pitch For Offset Printed Carton

WHOLE MACHINE FEATURES:

I. Core Performance Parameters



Servo-driven high-speed semi-automatic stitching system with a peak capacity of 500 nails/minute, equipped with quick-change mechanisms for seamless multi-format conversion.



Ergonomic HMI design enables operators with zero experience to achieve proficiency within 30 minutes.



Dual-mode stitching system: Supports intelligent switching between single/double-layer cardboard.



II. Intelligent Control System


Integrated production counter  automatic bundling unit.


Computerized parameter control system:



  • Dynamic stitching speed adjustment (200–500 nails/minute)

  •

  • Real-time production data and fault diagnostics via 7-inch industrial touchscreen.

  •

III. Precision Positioning System


Infrared photoelectric sensing platform.



  • Auto-lifting positioning accuracy.

  •

  • Adaptive feeding height compensation

  •

  • Manual fine-tuning baffle

  •

IV. Structural Safety Design


Precision bearing components from FAG (Germany) and NSK (Japan).


Dual safety protection mechanisms.



  • Overload auto-shutdown protection

  •

V. Product Compatibility


Staple compatibility: Standard single staples, reinforced double staples, and special-shaped staples.


  • Standard adaptation: 3-/5-layer corrugated cartons

  •

  • Custom solutions: 7-layer heavy-duty cartons (including lidless configurations).



9 KW Semi Automatic Gluer Machine Pitch For Offset Printed Carton 0


MAIN SPARE PARTS:

Japanese YASKAWA ELECTRIC servo motor .

Japanese OMRON PLC programmed.

Japanese YASKAWA ELECTRIC servo motor Control.

Japanese NSK Bearing. TR bearing with set.

Electric switch & contactor: Taiwan brand. Almost Electric: Germany SIEMENS and France Schneider.

Stitching head use Japanese molding design. CNC precision treated.

Blade and bottom mould used Germany Tungsten steel. And Japanese SKD11 alloy steel puncher pin that anti-friction and rot.

All transmission gears are hardened and ground, HRC 58-60°.

Germany Air-tec pneumatic cylinder adopted.

America BANNER/ Taiwan Fotek / Taiwan Wunlun Color Touch Screen.
MODEL
WM-XX2-1800
Machine speed
500 Nail/min
Stitching distance(D)
30-120 mm
No. of Stitching
1-99钉
Paperboard thickness
3-10mm
Stitching wire
17#(2.0x1.0mm);18#(1.8x0.8mm)
Max (A+B)X2
3600mm
Min (A+B)X2
1060mm
Max Length(A)
1450mm
Min. Length(A)
350mm
Max Width(B)
800mm
Min Width(B)
180mm
Side mark(C)
125-500mm
Stitching flap
30-45mm
The first stitching
20-380mm
Voltage (Three variable)frequency)
380v 415V
Total power
12HP 5kw
Machine size
4000X3300mm
Machine weight
3000KG
feeding height
900mm
Nails Type
Single/ / / Double// // MIX/ // /
